트로마츠 기술 상용화 연구소

[생체전류를 활용한 전기적 미생물막 제거, Nature research (Sep 23, 2015)]

전기적 미생물막 제거 원리

트로마츠웨이브는 전기적인 힘으로 미생물막을 제거하는 생체친화 전자기파입니다. 인체에 무해한 수준의 미세전류를 이용해 비침습적(noninvasion)인 방법으로 미생물막을 표면으로부터 분리시킵니다.
직류와 교류의 혼합에 의한 시너지 효과 (Y.W. Kim, Doctor of Philosophy, University of Maryland, 2014)
Y.W. Kim, 2015, Effect of electrical energy on the efficacy of biofilm treatment using the bioelectriceffect NatureResearch 게재 논문
직류와 교류의 매커니즘을 동시에 적용하여 미세한 전류로도 미생물막에 월등히 우수한 멸균 효과를 보입니다. 직류는 한 방향으로 정전기 인력을 지속적으로 가할 뿐만 아니라 매질에 미세한 가수분해를 일으켜 미생물막을 표면에서 분리하는 기능을 하며, 교류의 경우 일정한 주파수의 진동을 지속적으로 유발하여 미생물막의 투과성을 높이는 효과로 제거 효율성을 높입니다. 트로마츠웨이브는 이 두가지 원리를 동시에 적용하여 미생물막 제거 효과를 극대화 하였으며, 해당 기술의 원천연구가 NatureResearch지를 포함한 많은 저명한 저널에 게재되어 효과를 입증받았습니다.
In the case of a DC voltage, the generation of radicals owing to media electrolysis is suggested as a principal factor.¹ ² ³ In addition, some reports describe enhanced efficacy owing to improved antibiotic binding to biofilms⁴ and enhanced biofilm detachment⁵ from an external DC electrostatic force. 1. Stoodley P, deBeer D, Lappin-Scott HM. Influence of electric fields and pH on biofilm structure as related to the bioelectric effect. Antimicrob Agents Chemother 1997; 41: 1876–1879. 2. Stewart PS, Wattanakaroon W, Goodrum L, Fortun SM, McLeod BR. Electrolytic generation of oxygen partially explains electrical enhancement of tobramycin efficacy against Pseudomonas aeruginosa biofilm. Antimicrob Agents Chemother 1999; 43: 292–296. 3. Sandvik EL, McLeod BR, Parker AE, Stewart PS. Direct electric current treatment under physiologic saline conditions kills Staphylococcus epidermidis biofilms via electrolytic generation of hypochlorous acid. PLoS One 2013; 8: e55118. 4. Del Pozo JL, Rouse MS, Patel R. Bioelectric effect and bacterial biofilms. A systematic review. Int J Artif Organs 2008; 31: 786–795. 5. Van Der Borden AJ, Van Der Werf H, Van Der Mei HC, Busscher HJ. Electric current-induced detachment of Staphylococcus epidermidis biofilms from surgical stainless steel. Appl Environ Microbiol 2004; 70: 6871–6874
In the case of the AC treatment, results indicate increased permeability of the exopolysaccharide matrix because of locally charged molecular vibrations.⁶ Other reports note augmented effects from thermal stimuli⁷ as well as electrolysis of the medium.⁴ In general, investigating the mechanisms that underlie the bioelectric effect on biofilms is difficult owing to their complex structures and the diverse stimuli.⁴ 6. Giladi M, Porat Y, Blatt A, Shmueli E, Wasserman Y, Kirson ED et al. Microbial growth inhibition by alternating electric fields in mice with Pseudomonas aeruginosa lung infection. Antimicrob Agents Chemother 2010; 54: 3212–3218. 7. Caubet R, Pedarros-Caubet F, Chu M, Freye E, de Belem Rodrigues M, Moreau J et al. A radio frequency electric current enhances antibiotic efficacy against bacterial biofilms. Antimicrob Agents Chemother 2004; 48: 4662–4664.

세계 최초 상용화 제품, 트로마츠 오랄케어

트로마츠 기술은 비침습적으로 미생물막을 제거하는 기술으로, 물리적/화학적 자극이나 외과적 수술 없이도 미생물막 문제를 해결할 수 있습니다. 트로마츠웨이브를 세계 최초로 상용화한 오랄케어 디바이스인 트로마츠 칫솔은 구강 내 미생물막인 치태를 치아 마모 없이 제거하는데 탁월한 효과가 있음이 검증되었습니다.
갤러리 보기
